EventBus 是人们在日常开发中经常会用到的开源库，即使是不直接用的人，也多少借鉴过事件总线的用法。而且EventBus的代码其实是非常简单的，可以试着阅读一下。
源码阅读系列不采用对功能进行归类的方法进行阅读，而是采用一个刚开始阅读源码的视角，从我们平时的API调用，一步步的去理解设计意图和实现原理。
从这里开始
从这里开始吧，我们最常用的地方就是给一个函数添加上注解，我们先抛开apt生成的table，只看这个运行时版本的订阅设定。
// eventbus/Subscribe@Documented@Retention(RetentionPolicy.RUNTIME)@Target({ElementType.METHOD})public @interface Subscribe { ThreadMode threadMode() default ThreadMode.POSTING; /** * If true, delivers the most recent sticky event (posted with * {@link EventBus#postSticky(Object)}) to this subscriber (if event available). */
boolean sticky() default false; /** Subscriber priority to influence the order of event delivery. * Within the same delivery thread ({@link ThreadMode}), higher priority subscribers will receive events before * others with a lower priority. The default priority is 0. Note: the priority does *NOT* affect the order of * delivery among subscribers with different {@link ThreadMode}s! */
int priority() default 0;
}这个设定还是非常简单的，而且都是我们熟悉的东西，线程类型（默认的是抛出线程），是否是粘性事件，时间的优先级。经过这个类的出现，我们就可以在类里面写我们经常写的某个函数是订阅函数了。
@Subscribe (...)public void getMessage(Event event) { ... }下面的问题是我们改怎么让EventBus找到这些方法呢？通过apt的版本我们知道这里面肯定有一个map或者是table的东西记录了Object和Method之间的订阅关系，而且还是一对多的。这个地方就是从每个我们进行register的地方进行的。
register & unregister
// eventbus/EventBus
/** * Registers the given subscriber to receive events. Subscribers must call {@link #unregister(Object)} once they * are no longer interested in receiving events. * <p/> * Subscribers have event handling methods that must be annotated by {@link Subscribe}. * The {@link Subscribe} annotation also allows configuration like {@link * ThreadMode} and priority. */ public void register(Object subscriber) { Class<?> subscriberClass = subscriber.getClass(); List<SubscriberMethod> subscriberMethods = subscriberMethodFinder.findSubscriberMethods(subscriberClass); synchronized (this) { for (SubscriberMethod subscriberMethod : subscriberMethods) { subscribe(subscriber, subscriberMethod); } } }我们在Activity／Fragment中都有可能会调用这个方法，如果是Fragment里面我们还会在onDestoryView()中进行unregister(...)。在这段函数里我们发现使用反射从这个Class中找到了所有的订阅者函数了，然后对每个订阅者函数进行注册。
这里我们看看我们的SubribeMethod被包装成了什么样子：
/** Used internally by EventBus and generated subscriber indexes. */public class SubscriberMethod { final Method method; final ThreadMode threadMode; final Class<?> eventType; final int priority; final boolean sticky; /** Used for efficient comparison */
String methodString; public SubscriberMethod(Method method, Class<?> eventType, ThreadMode threadMode, int priority, boolean sticky) { this.method = method; this.threadMode = threadMode; this.eventType = eventType; this.priority = priority; this.sticky = sticky;
} @Override
public boolean equals(Object other) { if (other == this) { return true;
} else if (other instanceof SubscriberMethod) { checkMethodString();
SubscriberMethod otherSubscriberMethod = (SubscriberMethod)other;
otherSubscriberMethod.checkMethodString(); // Don't use method.equals because of http://code.google.com/p/android/issues/detail?id=7811#c6
return methodString.equals(otherSubscriberMethod.methodString);
} else { return false;
}
} private synchronized void checkMethodString() { if (methodString == null) { // Method.toString has more overhead, just take relevant parts of the method
StringBuilder builder = new StringBuilder(64);
builder.append(method.getDeclaringClass().getName());
builder.append('#').append(method.getName());
builder.append('(').append(eventType.getName());
methodString = builder.toString();
}
} @Override
public int hashCode() { return method.hashCode();
}
}SubscribeMethod 携带了Method函数原型，还有就是我们在注解类里面提供的所有信息。还有一个Class<?>类型的EventType是指我们的事件类所对应的Class，其余的方法都是为了比较和判断是否相等来做的，equal/checkMethodString都是各种的拼字串来进行存储和判断。
下面我们来看register里面调用的这段subscribe，这段非常的重要涉及了EventBus运行时处理的绝大多数部分，还有就是粘性事件的分发。这段使用了大量的JDK的反射包的API，本身注释也提醒我们了这段代码需要加锁，毕竟里面这一堆并发容器。所以我们最好先明确这段里面用的并发容器到底都是什么，这段代码才好继续看的下去。
private final Map<Class<?>, CopyOnWriteArrayList<Subscription>> subscriptionsByEventType; private final Map<Object, List<Class<?>>> typesBySubscriber; private final Map<Class<?>, Object> stickyEvents;
主要的有这几个：
第一个Map存储的Key是Class类型，Value是一个并发的ArrayList里面存的是对订阅者和订阅函数的一种绑定类
Subscription从名字上也能看出Key是Event的Class对象。第二个存储的是订阅者（Activity什么的啊）和Event类型的List。
第三个Map存储的是粘性事件，Key是Event类型，Value是真实存在的StickyEvent对象。
知道这三个都是什么之后，这段代码就好看了。我们来看前一部分。
// Must be called in synchronized block
private void subscribe(Object subscriber, SubscriberMethod subscriberMethod) {
Class<?> eventType = subscriberMethod.eventType;
Subscription newSubscription = new Subscription(subscriber, subscriberMethod); // Map<Class<?>, CopyOnWriteArrayList<Subscription>>
CopyOnWriteArrayList<Subscription> subscriptions = subscriptionsByEventType.get(eventType) ; if (subscriptions == null) {
subscriptions = new CopyOnWriteArrayList<>();
subscriptionsByEventType.put(eventType, subscriptions);
} else { if (subscriptions.contains(newSubscription)) { throw new EventBusException("Subscriber " + subscriber.getClass() + " already registered to event "
+ eventType);
}
} int size = subscriptions.size(); for (int i = 0; i <= size; i++) { if (i == size || subscriberMethod.priority > subscriptions.get(i).subscriberMethod.priority) {
subscriptions.add(i, newSubscription); break;
}
}
List<Class<?>> subscribedEvents = typesBySubscriber.get(subscriber); if (subscribedEvents == null) {
subscribedEvents = new ArrayList<>();
typesBySubscriber.put(subscriber, subscribedEvents);
}
subscribedEvents.add(eventType);这段写的虽然有点乱套，但实际上写的挺简单的，而且一堆堆的O(n)遍历，性能也就那样(?)。
首先这里面出现了Subscription：
final class Subscription { final Object subscriber; final SubscriberMethod subscriberMethod; /** * Becomes false as soon as {@link EventBus#unregister(Object)} is called, which is checked by queued event delivery * {@link EventBus#invokeSubscriber(PendingPost)} to prevent race conditions. */
volatile boolean active; Subscription(Object subscriber, SubscriberMethod subscriberMethod) { this.subscriber = subscriber; this.subscriberMethod = subscriberMethod;
active = true;
} @Override
public boolean equals(Object other) { if (other instanceof Subscription) {
Subscription otherSubscription = (Subscription) other; return subscriber == otherSubscription.subscriber
&& subscriberMethod.equals(otherSubscription.subscriberMethod);
} else { return false;
}
} @Override
public int hashCode() { return subscriber.hashCode() + subscriberMethod.methodString.hashCode();
}
}我们发现了这是订阅者和订阅方法类的一个契约关系类。
所以说上面subscribe函数主要做了，
创建了订阅者和方法类的绑定，然后存进了
subscriptionsByEventType中对每个类型重新排列了一次优先级
对
typesBySubscriber添加了对应的类型
然后我们可以看一下这个函数的下一半，我们会惊奇地发现，StickyEvent的发送时机居然是在register的时候：
... if (subscriberMethod.sticky) { if (eventInheritance) { // Existing sticky events of all subclasses of eventType have to be considered.
// Note: Iterating over all events may be inefficient with lots of sticky events,
// thus data structure should be changed to allow a more efficient lookup
// (e.g. an additional map storing sub classes of super classes: Class -> List<Class>).
Set<Map.Entry<Class<?>, Object>> entries = stickyEvents.entrySet(); for (Map.Entry<Class<?>, Object> entry : entries) {
Class<?> candidateEventType = entry.getKey(); if (eventType.isAssignableFrom(candidateEventType)) {
Object stickyEvent = entry.getValue(); checkPostStickyEventToSubscription(newSubscription, stickyEvent);
}
}
} else {
Object stickyEvent = stickyEvents.get(eventType); checkPostStickyEventToSubscription(newSubscription, stickyEvent);
}
}这时候轮了一遍所有的粘性事件。isAssignableFrom类似于使用在Class之间的instance of 就是判断两个类是否有相同的接口关系，也就是说有继承和实现关系的事件类，都会被判断处理。
private void checkPostStickyEventToSubscription(Subscription newSubscription, Object stickyEvent) { if (stickyEvent != null) { // If the subscriber is trying to abort the event, it will fail (event is not tracked in posting state)
// --> Strange corner case, which we don't take care of here.
postToSubscription(newSubscription, stickyEvent, Looper.getMainLooper() == Looper.myLooper());
}
} private void postToSubscription(Subscription subscription, Object event, boolean isMainThread) { switch (subscription.subscriberMethod.threadMode) { case POSTING: invokeSubscriber(subscription, event); break; case MAIN: if (isMainThread) { invokeSubscriber(subscription, event);
} else {
mainThreadPoster.enqueue(subscription, event);
} break; case BACKGROUND: if (isMainThread) {
backgroundPoster.enqueue(subscription, event);
} else { invokeSubscriber(subscription, event);
} break; case ASYNC:
asyncPoster.enqueue(subscription, event); break; default: throw new IllegalStateException("Unknown thread mode: " + subscription.subscriberMethod.threadMode);
}
}之后就是针对各种的ThreadMode进行了处理，同一线程的直接依赖Java的反射invoke执行了，各种不可以的情况，比如说发到主线程但还没在主线程的时候，都是用队列进行发送到对应线程。
接下来我们看看这里面在各线程之间的发送是怎么实现的。
消息转换线程
我们发现在Subscription和event入队的时候我们把他们封装成了一个PendingPost类：
// HandlePoster void enqueue(Subscription subscription, Object event) {
PendingPost pendingPost = PendingPost.obtainPendingPost(subscription, event); synchronized (this) {
queue.enqueue(pendingPost); if (!handlerActive) {
handlerActive = true; if (!sendMessage(obtainMessage())) { throw new EventBusException("Could not send handler message");
}
}
}
}然后才进行的入队和发送，这个PendingPost就是一个带有回收池的掩饰传送类：
final class PendingPost { private final static List<PendingPost> pendingPostPool = new ArrayList<PendingPost>();
Object event;
Subscription subscription;
PendingPost next; private PendingPost(Object event, Subscription subscription) { this.event = event; this.subscription = subscription;
} static PendingPost obtainPendingPost(Subscription subscription, Object event) { synchronized (pendingPostPool) { int size = pendingPostPool.size(); if (size > 0) {
PendingPost pendingPost = pendingPostPool.remove(size - 1);
pendingPost.event = event;
pendingPost.subscription = subscription;
pendingPost.next = null; return pendingPost;
}
} return new PendingPost(event, subscription);
} static void releasePendingPost(PendingPost pendingPost) {
pendingPost.event = null;
pendingPost.subscription = null;
pendingPost.next = null; synchronized (pendingPostPool) { // Don't let the pool grow indefinitely
if (pendingPostPool.size() < 10000) {
pendingPostPool.add(pendingPost);
}
}
}
}这里的设计其实挺不错的，一个静态的回收池，初始化靠一个静态方法，优先使用被回收的对象，实现和Message其实很像。另一个release方法就是把用完的对象回收起来。
PendingPostQueue 就是一个PendingPost的队列，里面的操作基本上就是入队出队之类的，有点特殊的是入队和出队都有一把锁。
接着这个队列被用在了好几个Poster类中，实现了向各个线程的消息转换，首先我们来看向主线程发送数据的:
HandlePoster
final class HandlerPoster extends Handler { private final PendingPostQueue queue; private final int maxMillisInsideHandleMessage; private final EventBus eventBus; private boolean handlerActive; HandlerPoster(EventBus eventBus, Looper looper, int maxMillisInsideHandleMessage) { super(looper); this.eventBus = eventBus; this.maxMillisInsideHandleMessage = maxMillisInsideHandleMessage;
queue = new PendingPostQueue();
} void enqueue(Subscription subscription, Object event) {
PendingPost pendingPost = PendingPost.obtainPendingPost(subscription, event); synchronized (this) {
queue.enqueue(pendingPost); if (!handlerActive) {
handlerActive = true; if (!sendMessage(obtainMessage())) { throw new EventBusException("Could not send handler message");
}
}
}
} @Override
public void handleMessage(Message msg) { boolean rescheduled = false; try { long started = SystemClock.uptimeMillis(); while (true) {
PendingPost pendingPost = queue.poll(); if (pendingPost == null) { synchronized (this) { // Check again, this time in synchronized
pendingPost = queue.poll(); if (pendingPost == null) {
handlerActive = false; return;
}
}
}
eventBus.invokeSubscriber(pendingPost); long timeInMethod = SystemClock.uptimeMillis() - started; if (timeInMethod >= maxMillisInsideHandleMessage) { if (!sendMessage(obtainMessage())) { throw new EventBusException("Could not send handler message");
}
rescheduled = true; return;
}
}
} finally {
handlerActive = rescheduled;
}
}
}HandlePoster 继承自 Handler 再加上初始化的时候传进去的是Looper.getMainThread();所以能向主线程发送消息。每次入队之后都会发送一条空消息去通知handleMessage函数处理队列数据，使用handlerActive作为控制标记位。handleMessage是个死循环两段的if判断用来处理多线程的情况，invokeSubscriber的方式和之前类似。之后就是有一个阀值，当时间超过10ms的时候就会发一个消息重入，并且退出这次循环，这是防止时间太长阻塞主线程。
BackgroundPoster
final class BackgroundPoster implements Runnable { private final PendingPostQueue queue; private final EventBus eventBus; private volatile boolean executorRunning; BackgroundPoster(EventBus eventBus) { this.eventBus = eventBus;
queue = new PendingPostQueue();
} public void enqueue(Subscription subscription, Object event) {
PendingPost pendingPost = PendingPost.obtainPendingPost(subscription, event); synchronized (this) {
queue.enqueue(pendingPost); if (!executorRunning) {
executorRunning = true;
eventBus.getExecutorService().execute(this);
}
}
} @Override
public void run() { try { try { while (true) {
PendingPost pendingPost = queue.poll(1000); if (pendingPost == null) { synchronized (this) { // Check again, this time in synchronized
pendingPost = queue.poll(); if (pendingPost == null) {
executorRunning = false; return;
}
}
}
eventBus.invokeSubscriber(pendingPost);
}
} catch (InterruptedException e) {
Log.w("Event", Thread.currentThread().getName() + " was interruppted", e);
}
} finally {
executorRunning = false;
}
}
}BackgroundPoster 自身是一个Runnable ，入队之后就调用EventBus携带的一个线程池进行运行，同样也是一个死循环，用了一个生产者 vs 消费者模式 进行了有限等待，这1000ms内入队的消息都会被弹出处理。
synchronized PendingPost poll(int maxMillisToWait) throws InterruptedException { if (head == null) { wait(maxMillisToWait);
} return poll();
}PendingPostQueue的poll(int)方法对队列为空的情况进行了等待，唤醒则出现在enqueue:
synchronized void enqueue(PendingPost pendingPost) { if (pendingPost == null) { throw new NullPointerException("null cannot be enqueued");
} if (tail != null) {
tail.next = pendingPost;
tail = pendingPost;
} else if (head == null) {
head = tail = pendingPost;
} else { throw new IllegalStateException("Head present, but no tail");
} notifyAll(); // 在这进行了唤醒
}AsyncPoster
如果说Background尚且能保证在同一个线程内完成，AsyncPoster就完全进行了异步操作。
class AsyncPoster implements Runnable { private final PendingPostQueue queue; private final EventBus eventBus; AsyncPoster(EventBus eventBus) { this.eventBus = eventBus;
queue = new PendingPostQueue();
} public void enqueue(Subscription subscription, Object event) {
PendingPost pendingPost = PendingPost.obtainPendingPost(subscription, event);
queue.enqueue(pendingPost);
eventBus.getExecutorService().execute(this);
} @Override
public void run() {
PendingPost pendingPost = queue.poll(); if(pendingPost == null) { throw new IllegalStateException("No pending post available");
}
eventBus.invokeSubscriber(pendingPost);
}
}这里面基本上什么都不控制，直接就来一个运行一次，也不会有什么问题。。。
到这为止我们不但知道了方法是怎么注册和绑定的，我们甚至还知道了粘性事件是怎么发送的了，接着我们来看方法查找和普通事件的发送是怎么进行的。
方法查找
// package org.greenrobot.eventbus.meta;/** Base class for generated index classes created by annotation processing. */public interface SubscriberInfo { // 获取订阅的类
Class<?> getSubscriberClass(); // 所有的method
SubscriberMethod[] getSubscriberMethods(); // 获取父类的info
SubscriberInfo getSuperSubscriberInfo(); // 是否检查父类
boolean shouldCheckSuperclass();
}SubscriberInfo 描述了能通过注解类生成的Index的方法（具体功能我加了主食）。
/** * Interface for generated indexes. */public interface SubscriberInfoIndex { SubscriberInfo getSubscriberInfo(Class<?> subscriberClass);
}这个接口是查找info的。
另外可以说这其中的SubscriberMethodInfo存储着SubscriberMethod所需的元信息：
public class SubscriberMethodInfo { final String methodName; final ThreadMode threadMode; final Class<?> eventType; final int priority; final boolean sticky;
...AbstractSubscriberInfo是一个抽象类，主要负责从Info创建出Method，又是一个反射：
protected SubscriberMethod createSubscriberMethod(String methodName, Class<?> eventType, ThreadMode threadMode, int priority, boolean sticky) { try {
Method method = subscriberClass.getDeclaredMethod(methodName, eventType); return new SubscriberMethod(method, eventType, threadMode, priority, sticky);
} catch (NoSuchMethodException e) { throw new EventBusException("Could not find subscriber method in " + subscriberClass + ". Maybe a missing ProGuard rule?", e);
}
}另外还有一个SimpleSubscriberInfo作为他的子类。
接下来的SubscriberMethodFinder也非常重要运行时的方法查找都来自这里:
刚才我们在EventBus.register(...)中调用了这个函数：
List<SubscriberMethod> findSubscriberMethods(Class<?> subscriberClass) {
List<SubscriberMethod> subscriberMethods = METHOD_CACHE.get(subscriberClass); if (subscriberMethods != null) { return subscriberMethods;
} if (ignoreGeneratedIndex) {
subscriberMethods = findUsingReflection(subscriberClass);
} else {
subscriberMethods = findUsingInfo(subscriberClass);
} if (subscriberMethods.isEmpty()) { throw new EventBusException("Subscriber " + subscriberClass
+ " and its super classes have no public methods with the @Subscribe annotation");
} else {
METHOD_CACHE.put(subscriberClass, subscriberMethods); return subscriberMethods;
}
}其中的METHOD_CACHE是对每个类方法进行缓存，防止多次查找，毕竟运行时查找还是个复杂的操作，根据是否忽略生成Index。
private List<SubscriberMethod> findUsingReflection(Class<?> subscriberClass) {
FindState findState = prepareFindState();
findState.initForSubscriber(subscriberClass); while (findState.clazz != null) { findUsingReflectionInSingleClass(findState);
findState.moveToSuperclass();
} return getMethodsAndRelease(findState);
} private void findUsingReflectionInSingleClass(FindState findState) {
Method[] methods; try { // This is faster than getMethods, especially when subscribers are fat classes like Activities
methods = findState.clazz.getDeclaredMethods();
} catch (Throwable th) { // Workaround for java.lang.NoClassDefFoundError, see https://github.com/greenrobot/EventBus/issues/149
methods = findState.clazz.getMethods();
findState.skipSuperClasses = true;
} for (Method method : methods) { int modifiers = method.getModifiers(); if ((modifiers & Modifier.PUBLIC) != 0 && (modifiers & MODIFIERS_IGNORE) == 0) {
Class<?>[] parameterTypes = method.getParameterTypes(); if (parameterTypes.length == 1) {
Subscribe subscribeAnnotation = method.getAnnotation(Subscribe.class); if (subscribeAnnotation != null) {
Class<?> eventType = parameterTypes[0]; if (findState.checkAdd(method, eventType)) {
ThreadMode threadMode = subscribeAnnotation.threadMode();
findState.subscriberMethods.add(new SubscriberMethod(method, eventType, threadMode,
subscribeAnnotation.priority(), subscribeAnnotation.sticky()));
}
}
} else if (strictMethodVerification && method.isAnnotationPresent(Subscribe.class)) {
String methodName = method.getDeclaringClass().getName() + "." + method.getName(); throw new EventBusException("@Subscribe method " + methodName + "must have exactly 1 parameter but has " + parameterTypes.length);
}
} else if (strictMethodVerification && method.isAnnotationPresent(Subscribe.class)) {
String methodName = method.getDeclaringClass().getName() + "." + method.getName(); throw new EventBusException(methodName + " is a illegal @Subscribe method: must be public, non-static, and non-abstract");
}
}
}findUsingReflectionInSingleClass对反射类进行了处理，这里面通过掩模运算检查了访问权限， 检查了参数个数。
boolean checkAdd(Method method, Class<?> eventType) { // 2 level check: 1st level with event type only (fast), 2nd level with complete signature when required.
// Usually a subscriber doesn't have methods listening to the same event type.
Object existing = anyMethodByEventType.put(eventType, method); if (existing == null) { return true;
} else { if (existing instanceof Method) { if (!checkAddWithMethodSignature((Method) existing, eventType)) { // Paranoia check
throw new IllegalStateException();
} // Put any non-Method object to "consume" the existing Method
anyMethodByEventType.put(eventType, this);
} return checkAddWithMethodSignature(method, eventType);
}
}其中的checkAdd检查了类型和方法签名，每次轮转完成之后都会进行一次findState.moveToSuperclass();对父类进行处理。
使用索引
因为反射所使用的运行时查找速度缓慢，所以我们也经常会通过apt使用已经创建好的Index。
刚才另一个分支的findUsingInfo就是使用已有的Index:
private List<SubscriberMethod> findUsingInfo(Class<?> subscriberClass) {
FindState findState = prepareFindState();
findState.initForSubscriber(subscriberClass); while (findState.clazz != null) {
findState.subscriberInfo = getSubscriberInfo(findState); if (findState.subscriberInfo != null) {
SubscriberMethod[] array = findState.subscriberInfo.getSubscriberMethods(); for (SubscriberMethod subscriberMethod : array) { if (findState.checkAdd(subscriberMethod.method, subscriberMethod.eventType)) {
findState.subscriberMethods.add(subscriberMethod);
}
}
} else { findUsingReflectionInSingleClass(findState);
}
findState.moveToSuperclass();
} return getMethodsAndRelease(findState);
}这段非常简单，几乎就是刚才的验证而已，如果没拿到数据的话，还会进行正常的反射查找。
// EventBusAnnotationProcessor 负责生成注解路由表
private void createInfoIndexFile(String index) {
BufferedWriter writer = null; try {
JavaFileObject sourceFile = processingEnv.getFiler().createSourceFile(index); int period = index.lastIndexOf('.');
String myPackage = period > 0 ? index.substring(0, period) : null;
String clazz = index.substring(period + 1);
writer = new BufferedWriter(sourceFile.openWriter()); if (myPackage != null) {
writer.write("package " + myPackage + ";\n\n");
}
writer.write("import org.greenrobot.eventbus.meta.SimpleSubscriberInfo;\n");
writer.write("import org.greenrobot.eventbus.meta.SubscriberMethodInfo;\n");
writer.write("import org.greenrobot.eventbus.meta.SubscriberInfo;\n");
writer.write("import org.greenrobot.eventbus.meta.SubscriberInfoIndex;\n\n");
writer.write("import org.greenrobot.eventbus.ThreadMode;\n\n");
writer.write("import java.util.HashMap;\n");
writer.write("import java.util.Map;\n\n");
writer.write("/** This class is generated by EventBus, do not edit. */\n");
writer.write("public class " + clazz + " implements SubscriberInfoIndex {\n");
writer.write(" private static final Map<Class<?>, SubscriberInfo> SUBSCRIBER_INDEX;\n\n");
writer.write(" static {\n");
writer.write(" SUBSCRIBER_INDEX = new HashMap<Class<?>, SubscriberInfo>();\n\n"); writeIndexLines(writer, myPackage);
writer.write(" }\n\n");
writer.write(" private static void putIndex(SubscriberInfo info) {\n");
writer.write(" SUBSCRIBER_INDEX.put(info.getSubscriberClass(), info);\n");
writer.write(" }\n\n");
writer.write(" @Override\n");
writer.write(" public SubscriberInfo getSubscriberInfo(Class<?> subscriberClass) {\n");
writer.write(" SubscriberInfo info = SUBSCRIBER_INDEX.get(subscriberClass);\n");
writer.write(" if (info != null) {\n");
writer.write(" return info;\n");
writer.write(" } else {\n");
writer.write(" return null;\n");
writer.write(" }\n");
writer.write(" }\n");
writer.write("}\n");
} catch (IOException e) { throw new RuntimeException("Could not write source for " + index, e);
} finally { if (writer != null) { try {
writer.close();
} catch (IOException e) { //Silent
}
}
}
} private void writeIndexLines(BufferedWriter writer, String myPackage) throws IOException { for (TypeElement subscriberTypeElement : methodsByClass.keySet()) { if (classesToSkip.contains(subscriberTypeElement)) { continue;
}
String subscriberClass = getClassString(subscriberTypeElement, myPackage); if (isVisible(myPackage, subscriberTypeElement)) { writeLine(writer, 2, "putIndex(new SimpleSubscriberInfo(" + subscriberClass + ".class,", "true,", "new SubscriberMethodInfo[] {");
List<ExecutableElement> methods = methodsByClass.get(subscriberTypeElement); writeCreateSubscriberMethods(writer, methods, "new SubscriberMethodInfo", myPackage);
writer.write(" }));\n\n");
} else {
writer.write(" // Subscriber not visible to index: " + subscriberClass + "\n");
}
}
}有了这两个方法之后我们就知道，平常的index就是通过这种方式拼接出来的。
Post消息
/** Posts the given event to the event bus. */
public void post(Object event) {
PostingThreadState postingState = currentPostingThreadState.get();
List<Object> eventQueue = postingState.eventQueue;
eventQueue.add(event); if (!postingState.isPosting) {
postingState.isMainThread = Looper.getMainLooper() == Looper.myLooper();
postingState.isPosting = true; if (postingState.canceled) { throw new EventBusException("Internal error. Abort state was not reset");
} try { while (!eventQueue.isEmpty()) { postSingleEvent(eventQueue.remove(0), postingState);
}
} finally {
postingState.isPosting = false;
postingState.isMainThread = false;
}
}
}PostingThreadState是一个存储在ThreadLocal中的对象，包含有以下各种内容，线程信息，是否是主线程，是否取消，还有一个相应的事件队列。
private void postSingleEvent(Object event, PostingThreadState postingState) throws Error {
Class<?> eventClass = event.getClass(); boolean subscriptionFound = false; if (eventInheritance) { /** Looks up all Class objects including super classes and interfaces. Should also work for interfaces. */
List<Class<?>> eventTypes = lookupAllEventTypes(eventClass); int countTypes = eventTypes.size(); // 对所有的订阅函数，都调用发送数据
for (int h = 0; h < countTypes; h++) { // 所有的订阅类
Class<?> clazz = eventTypes.get(h);
subscriptionFound |= postSingleEventForEventType(event, postingState, clazz);
}
} else { // 只发送一次
subscriptionFound = postSingleEventForEventType(event, postingState, eventClass);
} if (!subscriptionFound) { if (logNoSubscriberMessages) {
Log.d(TAG, "No subscribers registered for event " + eventClass);
} if (sendNoSubscriberEvent && eventClass != NoSubscriberEvent.class &&
eventClass != SubscriberExceptionEvent.class) { // 无订阅者的处理
post(new NoSubscriberEvent(this, event));
}
}
}之后：
private boolean postSingleEventForEventType(Object event, PostingThreadState postingState, Class<?> eventClass) {
CopyOnWriteArrayList<Subscription> subscriptions; synchronized (this) {
subscriptions = subscriptionsByEventType.get(eventClass);
} if (subscriptions != null && !subscriptions.isEmpty()) { for (Subscription subscription : subscriptions) {
postingState.event = event;
postingState.subscription = subscription; boolean aborted = false; try { postToSubscription(subscription, event, postingState.isMainThread);
aborted = postingState.canceled;
} finally {
postingState.event = null;
postingState.subscription = null;
postingState.canceled = false;
} if (aborted) { break;
}
} return true;
} return false;
}之后对所有的订阅类的所有订阅者都发送一次数据，发送数据方法和上文相同。
发送粘性数据就是拿锁然后保存到队列中去,这样就可以在重新发送：
public void postSticky(Object event) { synchronized (stickyEvents) {
stickyEvents.put(event.getClass(), event);
} // Should be posted after it is putted, in case the subscriber wants to remove immediately
post(event);
}因为我们无法确定什么时候粘性事件应该停止继续传播，这取决于我们应用的需要，所以我们应当手动remove掉Sticky Event ：
// 系统提供了如下方法
public <T> T removeStickyEvent(Class<T> eventType) { synchronized (stickyEvents) { return eventType.cast(stickyEvents.remove(eventType));
}
} public boolean removeStickyEvent(Object event) { synchronized (stickyEvents) {
Class<?> eventType = event.getClass();
Object existingEvent = stickyEvents.get(eventType); if (event.equals(existingEvent)) {
stickyEvents.remove(eventType); return true;
} else { return false;
}
}
} public void removeAllStickyEvents() { synchronized (stickyEvents) {
stickyEvents.clear();
}
}延伸阅读
- 须臾小说在线阅读网站 2019-11-15 10:05:30.503
- [Android FrameWork 6.0源码学习] View的重绘过程之Measure 2017-07-26 16:27:03.317
- 【Jquery系列】之Jquery 选择器 2017-07-26 16:22:06.82
- CSS3学习系列之动画 2017-07-26 16:07:22.66
- RxSwift 系列(九) -- 那些难以理解的概念 前言 2017-07-26 15:50:59.93
- nopCommerce 3.9 大波浪系列 之 事件机制（生产者、消费者） 2017-07-26 15:49:39.443
- MS MDS系列之初识MS Master Data Service(微软主数据服务) 背景介绍： 2017-07-26 14:32:21.87
- ReactiveSwift源码解析(九) SignalProducerProtocol延展中的Start、Lift系列方法的代码实现 2017-07-26 12:00:35.793
- ABP从入门到精通（1）：aspnet-zero-core项目启动及各项目源码说明 2017-07-26 11:59:44.78
- .Net Core 系列：2、ADO.Net 基础 2017-07-26 11:54:44.893
须臾小说在线阅读网站
